Lost Wax Investment Casting

SHENGFA Hardware is using the precision lost wax investment castings method to prototype and produce products for the automobile, commercial, medical, and shipbuilding industries. We pour aluminum, stainless steel, bronze, and steel alloys to casting the products that satisfy our dear customers. We have been in the investment casting business as a manufacturer since 2007 in Ningbo China. During this 15 years history, we are always striving to have the highest quality products in the industry while continuously improving and expanding. SHENGFA uses our own tooling shop to create your lost wax investment castings as well as similar casting styles or specifications.

Send Inquiry

Product Description


Lost wax castings, also known as investment castings, or precision castings, is a well-known and popular metal casting process from 6000 years ago. Lost wax investment castings have remained the process of choice for many, then, especially due to its accuracy, ability to replicate details, repeatability and integrity. After centuries of use in the production of sculptural ornaments and in textile relief, lost wax investment castings began to be supplanted by piece-molding in 18th century Europe. Parts of the process were adapted for investment casting to meet the needs of growing industry in the 19th century.

Lost wax investment castings are adopted to make detailed, intricate metal components that are then applied to a variety of industries and situations. This technique might have originated thousands of years ago, then, but still playing a very important role in the casting of today.

SHENGFA Hardware has been providing its lost wax investment castings service since 2007 in Ningbo China as a superior manufacturer with good quality and reasonable price, considerate service. With more than 15 years experiences in this business, we have extensive knowledge and experience to cast a large range of ferrous, non-ferrous and exotic metals.



Lost wax investment castings details:

Material
Aluminum Alloy: 5052 /6061/ 6063 / 2017 / 7075 / etc.
Brass Alloy: 3600/ 3602 / 2604 / H59 / H62 / etc.
Stainless Steel Alloy: 303 / 304 / 316 / 412 / etc.
Steel Alloy: Carbon Steel / Die Steel / etc.
Titanium Alloy: Grade 1/Grade 2/Grade 2 H/Grade 3/Grade 5/etc.
We handle many other types of materials. Please contact us if your required material is not listed above.
Process
Lost wax casting + CNC machining
Casting dimension tolerance
CT7
Casting surface roughness
Ra 12.5um
Casting weight range
0.1-90kg
Casting Size
Max linear size: 1200mm, Max diameter size: 600mm
Machining Precision
Positioning accuracy 0.008mm, Rep. position. accuracy
0.006mm
Machining surface roughness
Ra0.8~6.3um
Max Travel Of Spindle
1800mmx850mmx700mm
Max Turning Diameter
1000mm
Material standard
GB, ASTM, AISI, DIN, BS, JIS, NF, AS, AAR.......
Surface treatment
KTL(E-coating), Zinc plating, Mirror Polishing, Sand Blasting,
Acid pickling, black oxide, Painting, Hot galvanizing, Powder
coating, Nickel plating
Service available
OEM & ODM
Quality control
0 defects,100% inspection before packing
Application
Aerospace industry: Jet engine airfoils. Trigger guards and black receiver.
Energy: Anvil, gate valve, wellhead control EQP, wellhead EQP.
Mining&Heavy machinery: Gear housings, Jaw plates, Rock breaker, Excavator parts
Agriculture machinery: Tractor parts, Root grapple rake attachment
Pumps&Valves: All kinds of pumps and valves.
Transportation: Cylinder heads, Engine support, Suspension arm, Front and Rear brake calipers.
